PURE Racing presents the TRAXION S fork designed for Surron Ultra Bee.
Tuning and performance specifications:
- Internal preload adjustment on both legs.
- External 24 click, compression and rebound adjustment.
- Hydraulic bottom out on both legs.
- 5 Spring weight tuning possibilities. (sold separately)
- 2 Valve tunes Trail & MX
Material and design specifications:
-
3D Printed Waffle Pistons located in upper and lower chambers of the internal cartridges, both for compression and rebound legs.
-
TiAlN (Titanium Aluminium Nitride) stanchion coating offers micro-level smoothness, superior lubrication, outstanding wear and scratch resistance, and excellent thermal stability.
-
Precision-honed inner cylinders with a ±0.01 mm tolerance, delivering exceptionally smooth damping and enhanced traction.
-
Custom-designed oil and dust seals strike an optimal balance between sealing efficiency and low friction, ensuring consistent oil flow over extensive use.
-
Advanced fluid dynamics provide a progressive, quiet, and controlled damping response.
-
The link plate, refined through FEM analysis, guarantees high rigidity, fatigue durability, and weight-optimized strength.
IN THE BOX:
Fork, CNC Crown, CNC Stem and lower bearing pre installed, headset spacers.
Not Included, Stanchion guards, Ultra Bee guards can be reused.
TECHNICAL SPECIFICATIONS:
NAME: TRAXION S
DROPOUTS: Surron Ultra Bee
TUBE DIAMETER: Inner 38mm/ Outer 50mm
STANCHIONS: Blue TiAlN Titanium Aluminium Nitride coated
TRAVEL: 260mm / EXTENDED LENGTH: 850mm
CROWN & STEM: Billet Aluminium, anodized coating
DAMPER: Dual sealed closed cartridges, dual-spring
RIDING STYLE OPTIONS: Light and Medium (TR) / Medium and Heavy (MX)
COMPRESSION & REBOUND DAMPING: 24-stage adjustable
WEIGHT: 9.8 Kg complete with oil, crown, handlebar clamps.
